Production & Quality Control
Automated production + precision inspection: every micron is strictly controlled.
Core Production Equipment
Introduce advanced domestic and international automation equipment to significantly boost production capacity and quality stability.
10/12/16-Axis Automatic Winding Machine
10, 12, and 16 axis fully servo motor automatic winding machines offer high efficiency and excellent stability.
12/16 axis skeleton loading, wire winding, and soldering automated production line
12-axis and 16-axis skeleton loading, wire winding, and soldering automated production line. Integrated functions for high efficiency and stability.
Automated Head Core Assembly Production Line
Features a multi-head linkage fully automatic modular design to manufacture precision, high-performance magnetic head core assemblies across various types through automated feeding, assembly, laser spot welding, and inspection.
Automatic Injection Molding Machine
1 8 Automatic Injection Molding Machine: High Precision, Superior Strength.
Automatic Dispensing Machine
1 6 automatic dispensing machine with precise positioning and uniform glue application.
M7450 High-Precision Vertical Spindle Surface Grinder
M7450 High-Precision Vertical Spindle Surface Grinder with stable feed and excellent flatness.
Precision Inspection Capability
Equipped with advanced precision testing instruments to ensure the quality of every product.
Measuring Microscope
Perform micrometer-level precision measurements on critical dimensions of key head components to strictly control machining accuracy.
Projector
Detects spot weld height and shape/location tolerances to effectively monitor welding process stability.
Inspection Microscope
Inspects head chip placement for misalignment, offset, and soldering quality to ensure internal structural consistency and reliability.
Image Measuring Instrument
Efficiently and precisely measure 2D/3D non-contact profiles, positional tolerances, concentricity, and more for various components to ensure full compliance with design specifications.
Hardness Tester
Measures hardness of copper and stainless steel parts, such as stents, to ensure raw materials meet design and process requirements for mechanical properties.
LCR Fully Automatic Bridge
Measures key electrical parameters of read/write heads—including inductance, resistance, and Q factor—with precision to ensure consistent and stable electrical performance.
Quality Control Process
End-to-end quality control from raw materials to shipment
Incoming Quality Control
Strict inspection of raw materials before warehousing
Process Inspection
Real-time monitoring of all production stages
Final Inspection
Full performance testing before shipment
Outgoing Inspection
Final quality check before packaging
